CNC Lathe
CNC Lathe
SC-42T
The SC-T series is a compound precision CNC lathe that combines the manufacturing know-how and advanced technologies that we have cultivated over many years.
SC-T CNC Lathe
The SC-T series is a compound precision CNC lathe that combines the manufacturing know-how and advanced technologies that we have cultivated over many years.
Although it is space-saving, it has high rigidity and high precision, and it is special for precision machining of high-quality small parts. The machine features high speed and lower production costs for bar machining. By the automatic feeding equipment and parts catcher, it can increase production efficiency to meet any requirements of any mass production.
Although it is space-saving, it has high rigidity and high precision, and it is special for precision machining of high-quality small parts. The machine features high speed and lower production costs for bar machining. By the automatic feeding equipment and parts catcher, it can increase production efficiency to meet any requirements of any mass production.
| Model | Unit | SC-42T |
|---|---|---|
| Max. turning diameter | mm | Ø200 |
| Max. turning length | mm | 140 |
| Max. bar capacity | mm | Ø42 |
| Bore of spindle | mm | Ø44 |
| Spindle bearing inside dia. | mm | Ø80 |
| Spindle nose | - | A2-5 |
| Spindle speed range | rpm | 45~3500 |
| Spindle motor | kw | 5.5 |
| Max. stroke X1/Z1-axis | mm | 215/150 |
| Rapid traverse X1/Z1-axis | m/min | 16 |
| Turret indexing time | sec | 0.3 |
| Machine slant degree | - | 20° |
| Slide way type | - | Square guideway |
| 3-jaw chuck size | - | 6" |
| Collet type | - | 173E |
| Turning tool size | mm | □20 |
| Boring tool diameter | mm | Ø25 |
| Cutting tool size | mm | □20 |
| X/Z axis ball screw dia | mm | Ø32 |
| X/Z axis feeding motor | kw | 0.75/1.0 |
| Hydraulic motor | kw | 0.75 |
| Lubrication motor | w | 150 |
| Power requirement | kva | 10 |
| Coolant tank capacity | L | 80 |
| Machine dimension (L x W x H) | mm | 2813x1350x1825 |
| Weight | kg | 2200 |
Standard Accessories
- Lighting device
- Coolant device
- Splash guard
- Tools & tool box
- Base block 4pcs
- Inner cutting tool sleeve Ø8, 10, 12, 16,20mm
- Foot switch
- Collet chuck holder
- Heat exchanger
- Operation manual
- NC control operation manual
- NC control maintenance manual
- 8-position hydraulic turret
Optional Accessories
- 6" 3-jaw chuck
- Material stop bar
- ER20 collets set
- Chip conveyor
- Parts conveyor
- Chip cart
- Parts catcher
- 2-position end drilling device
- 2-position side drilling device
- CE certification
- 6,000 rpm spindle speed
- Transformer
- Voltage stabilizer
- Chuck air blow
- 5° multiple cycle setting device
- Hydraulic bar feed 3.2M
